On the Wrangler TJ, coil springs and shocks are primary determining factors in ride quality and suspension performance. Skyjacker 2-Stage Variable Rate Springs deliver a smooth controlled comfortable ride.
First Flex Rate stage delivers a comfortable ride with the ability to flex\expand during full articulation as the suspension drops (full droop). This keeps the coil springs seated in the upper coil mount\bucket and the tires in contact with the terrain. Second Ride Rate stage only engages after compression past Flex Rate.
Skyjacker’s ADX M2.0 Adventure Series Aluminum Monotube Shocks deliver modern technology in the design with an innovative off-road race-inspired full-displaced valving system. With this highest level of technology development, ADX M2.0 provides consistent dampening, high-end performance, cooler running, more control and improved driving comfort.
Skyjacker’s ADX M2.0 shocks dampen out (control) the unwanted oscillation motion to improve handling and ride quality. ADX M2.0 will optimize your suspension by keeping your tires in contact with the terrain. Engineered for higher speed applications, but still perform great at a crawl.
Truthfully, we actually spend way more time on our daily commutes than we spend on the trails. The commutes are neither smooth surfaces or free of obstacles. Quick starts, up and down acceleration and hard stops are a daily routine.
The ADX M2.0 shocks separate the nitrogen gas from the oil with an Internal Floating Piston (IFP). ADX M2.0 constant controlled resistance performance prevents lag (decline) or fade (failure). The high-pressure nitrogen gas and IFP technology combine to create the fastest responding shock ever.
The 46mm (1.81 Inch) large bore size design reacts quicker and creates the smoothest ride possible. The Teflon banded piston’s smooth reaction delivers a superior ride and adds stability on any terrain.
Impact extruded CNC machined T6061-T6 aluminum monotube dissipates heat and runs cooler versus traditional steel-bodied shocks. The overall weight of the aluminum body is lighter as well.
The superior construction of Skyjacker’s ADX M2.0 will conquer off-road and on-road challenges through all manners of terrain, obstacles and extreme weather. Load up, set your waypoint where X marks the spot and confidently conquer your next adventure to the far end of the trail and back again.
Front and Rear Value Flex Lower Links adjustability allows proper caster settings to improve handling. Formed from 2-inch OD x 0.250 wall DOM tubing with pressed-in OEM style steel encased rubber bushings at the frame and the axle mount has Rock Jock’s 1-1/4-inch forged Johnny Joints. These Johnny Joints provide over 30 degrees of unrestricted Flex movement in any direction.
A Transfer Case Lowering Kit corrects rear driveshaft angle. Transfer Case Linkage Relocation Bracket included. Front Double Disconnect Sway Bar End Links allow full articulation at full droop. Front and Rear Bump Stop Spacers prevent over-compression.
Longer Rear Sway Bar End Links prevent bar pre-load. Rear Track Bar Lower Axle Mount Bracket corrects track bar angle.
Front Steering Box Skid Plate protects your essential steering box from hard-hitting rocks and trail debris.
