The next generation of winch technology arrives with a compact, all-in-one motor control design that delivers clean fitment and smooth, reliable operation. Built with top-tier components and validated through rigorous performance testing, the integrated motor control unit sits within the winch itself, allowing it to work seamlessly with modern bumpers and vehicle sensors.
Features & Benefits
- The ARB Winch features a custom Albright contactor that connects directly to the motor. This improvement increases efficiency and removes the need for a bulky control box.
- A 500A isolation switch with universal mount is included with the ARB Winch. It comes complete with a stainless lanyard and dust cover for safe and reliable operation.
- Gearbox-mounted brake ensures 100% load holding and allows powered unspooling under no load without damaging the winch, easing unspooling efforts.
- 4-Stage Gearbox with hardened steel gears provides superior load distribution with, the 171:1 ratio allows for fast line speed while maintaining pulling power.
- Dual connection remote with 2.4GHz wireless with sealed receiver circuitry for a stronger, secure connection eliminating interference or remote conflict.
- Remote mounted control plug for low profile or hidden winch mounting without losing the ability to hardwire the controller.
- One piece bridging plate offers greater torsional strength.
- Prewired connections, versatile mounting options, and preset clutch positioning allow for fast and hassle-free installation. 16 positions (22.5 deg) for clocking the clutch handle for more installation options.
Control Wirelessly or Hardwired
Control wirelessly up to 130ft. or utilize the hardwired connection up to 16ft, whatever the situation calls for.
- Compact hand controller with 130ft range and 16ft lead
- Remote-mounted control plug for hidden installs
- 2.4GHz wireless connection prevents interference
- 500A power isolation switch with stainless lanyard and cover
65 FT / MIN Line Speed
5.7HP Motor
11mm x 79ft Grey Synthetic Rope
