King bump stops provide an additional level of bottoming control when you are using every bit of suspension travel available. These bump stops are offered in 2.0 and 2.5 inch diameter bodies with stroke lengths from 2 to 4 inches to fit any mounting location requirements and handle any suspension arresting loads. The 4130 Chromoly mounting sleeves are precision machined to size and offer a secure and sturdy mount without pinching the bump stop body. The unique Schrader cover mounts to the housing not the Schrader valve itself to protect it and acts as a double seal to keep dust and moisture out. The bump stops contain a unique piston design that offers superior flow characteristics and the same quality micro polished shafts and advanced seal technology as our race shocks. The long wearing nylon contact pad insures quiet operation and mounts with a simple yet effective single bolt design. King bump stops help you use all the suspension travel you have to get the most out of your vehicle. They are easily tuned and serviced with simple hand tools.
- Adjustable up to 400 PSI
- Fully re-buildable and re-valvable
- Unique bump stop piston generates massive compression forces
- Aircraft quality jam nut
- Honed and polished bores
- Heat treated stainless steel alloy valving for longevity and strength
- Triple stage seals ensure no leaks even under the most extreme conditions
- Main seal is rated to 3000 psi
- High pressure schrader valve
- Unique schrader cover protects valve from rock damage and breakage
- High quality seal is incorporated into schrader cover eliminating gas pressure loss
Extended Length 10.65
Compressed Length 8.15
